Pinhole PRO Square Fixed IP65 - Fully Customizable
Featuring a deeply recessed light source and a matt black internal baffle, Pinhole PRO Square Fixed effectively reduces glare while creating a warm and inviting atmosphere. For an even more streamlined look, we also offer a flush mount variant.
Pinhole PRO Square Fixed IP65 offers certified fire protection of 30 or 90 minutes when installed in fire rated solid joist ceilings, and 30 minutes in fire rated metal web and I-Joist constructions.
| Lamp Required: | No |
|---|---|
| Light Source: | Integrated LED |
| Max Lamp Type & Wattage: | 1 x 10.3W LED |
| Type Of Dimmer: | DALI |
| Class: | Class III - Low Voltage |
| Power Connection Type: | Wired In |
| Bathroom Zone: | Zone 1, 2, 3 |
| IP Rating: | IP65 |
| Fire Rated: | Yes |
| Recess Depth (mm): | 150 |
| Cutout Shape: | Round |
| Hole Saw Diameter: | 70mm / 2-3/4in |
